Cooling system did not need to be drained, just syphoned out, and replaced with a new coolant tank. RPCF000160. including warning modules.

The heater matrix valve is basically a SAAB C900 unit usually comes supplied with 4 new coolant hoses attached, these cars are now old.

Coolant elbow In conventional systems, the thermostat is usually located on the outlet from the engine, the K Series is at the rear.

Sump now cleaned, and with new LVF-100290 gasket, ready to go back onto the 200, filled with oil and new oil filter fitted, prior to a run out.

Our none messy filling procedure, to insert into the filler hole, a clear plastic tube attached to a base removed old redex container.

With column covers removed, gave better access to the 2 small screws that holds ignition switch to barrel. At this stage it can be detached, from the multi-connector.

The ignition leads and the coil pack set up in the 2004 ZR shown Comprises of Leoni high tension leads, Denso 100730 coil packs.

Information page concentrates specifically on our 2004 MG ZR engine bay fuse box, and which circuit each fuse, fusible links, and relays serves and protects.

Information page concentrates specifically on our 2004 MG ZR cabin located fuse box, of which circuit each fuse, and relays protects.

Replacing the useless single horn of the MG, and then adding a much more responsive twin horn installation and even better.

Wires inside the sleeve constantly fold over each other every time the tailgate is in use, so will fray and eventually break, damaged wires will create electrical problems.

Sunroof panel tilted, showing one side of the 6 bolts, after removing the two plastic side panel covers, access to remove them can be done with the roof closed.

Shown located on top of the charcoal canister. The canister is fixed into a metal bracket containing an isolation rubber on the bulkhead, bad condition of the rubber.

To release the fuel filter unions a 14mm and 19mm open ended spanners were both used as shown. Then an 8mm spanner for releasing the fuel filter from the bulkhead.

Not all emissions tests are going to be successful, a short and direct drive to the testing station is one of them, engine may be hot, but wont be at its full working temperature.

On a 'cold engine' with vehicle on level ground, the tube is inserted into dipstick tube, after a few seconds thumb pressure is then applied to hold a vacuum.

The 4 x 8mm throttle body bolts were removed, easier and less of a disturbance with accelerator cable still attached, safe and not actually going anywhere.

Camshaft's bearing carrier's 26 x 10mm bolts, were then torqued to the shown specific order of 1 to 26 to just 10Nm or 7lb ft. with sealant..

Listed below are a small and random selection from our original 2004 spanners, and sockets, applications guide with part numbers.

Includes a list of 300, which is most or all of the MG-Rover original vehicle paint codes listed as AAC to ZGN from year 1963 up to 2005.
